Camera
| Name | 4K UHD AI Webcam with mic and camera Video Bar |
|---|---|
| Pixels | 8.42 MP |
| Digital Zoom | 5X |
| FOV | D: 119", H: 110", V: 72" |
| Resolution | 4K@30 |
| Focus | Fixed Focus |
| Al Modes | Single person tracking, speaker tracking, participant tracking, close-up of speaker |
| Backlight compensation | Support |
| SNR | >55db |
| Digital Noise Reduction | 2D\& 3D |
PTZ
| Rotation | pan:±10°, tile:±10° |
|---|---|
| Preset | 3 |
| Digital Board | 5X |
| USB Features | USB3.0 |
| Connection Type, Color Space, Communication Protocol | UVC1.0, UAC, UVC PTZ Control(Support ePTZ) YUY2, NV12 |
Interfaces
| HD Interface | 1xHDMI |
|---|---|
| USB Interface | 1 x USB 3.0, Type-B |
| USB Interface | 1 x USB 3.0, Type-B |
| USB Interface | 1 x USB 3.0, Type-B |
| USB Interface | 1 x USB 3.0, Type-B |
| USB Interface | 1 x USB 3.0, Type-B |
Interfaces
| HD Interface | 1xHDMI |
|---|---|
| USB Interface | 1 x USB 3.0, Type-B |
| Network Interface | 1 x RJ45: 10/100/1000M Adaptive Ethernet |
| WiFi(Optional) | 2.4G WiFi, Support WiFi Dongle |
| Antenna Interface (optional, only apply with Wifi) | 1, ANT |
| Power Interface | 1, DC12V |
Compatibility
| USB Compatibility | Windows 10 or higher, MACOS 10.10 or higher |
|---|
Size & Weight
| Dimension | 522.7*107.5*135.3mm |
|---|---|
| Weight | 2.4 KG |
| Installation | Including desktop tripod(can be installed on TV) and wall mount |
Video
| Scenario | Medium and huddle rooms, 4-6 participants |
|---|---|
| Video Signals | MJPEG: 3840*2160P@30/25fps, 1920*1080P@60/50/30/25fps, 1280*720P@60/50/30/25fps H.264: 3840*2160P@30/25fps, 1920*1080P@60/50/30/25fps, 1280*720P@60/50/30/25fps, YUY2/NV12:1920*1080P@30/25fps, 1280*720P@30/25fps, 640*480P@30/25fps |
| Video Encoding Format | H.265/H.264/MJPEG |
| Network Protocol | RTSP, RTMP |
Video
| Scenario | Medium and huddle rooms, 4-6 participants |
|---|---|
| Video Signals | MJPEG: 3840*2160P@30/25fps, 1920*1080P@60/50/30/25fps, 1280*720P@60/50/30/25fps H.264: 3840*2160P@30/25fps, 1920*1080P@60/50/30/25fps, 1280*720P@60/50/30/25fps, YUY2/NV12:1920*1080P@30/25fps, 1280*720P@30/25fps, 640*480P@30/25fps |
| Video Encoding Format | H.265/H.264/MJPEG |
| Network Protocol | RTSP, RTMP |
