MaxHub Interactive Flat Panel 75" | With OPS | 3840 x 2160 | Best for Online Teaching | 4K Display | E2 Series

MaxHub Interactive Flat Panel 75" | With OPS | 3840 x 2160 | Best for Online Teaching | 4K Display | E2 Series

Regular price Rs. 161,016.95
Regular price Sale price Rs. 161,016.95
Sale Sold out
Size
brand
model number

 Get Best offer price

MaxHub  Interactive Flat Panel
MaxHub Interactive Flat Panel does justice to your needs with its interactive screen of 75 inches. It comes with OPS and is of the E2 series. Maxhub Interactive Flat Pane increases engagement with its professional 4k display and high color accuracy. it is also perfectly suitable for corporate meetings.

Maxhub Interactive Flat Panel 75 inches with OPS

Professional 4K Display

High Color Accuracy, AE≤2 Wide Color Gamut, NTSC 72%

Versatile USB Type-C

 Integrate 65-watt power charge, video, audio, touch, and internet access features into one interface

Eyes Care

 TUV Low Blue light, TUV Flicker-free with ambient light sensor and anti-glare glass

Natural Writing Experience

 Less than 40ms writing latency in zero parallax screen

Productive Teaching

Preinstall with course delivery apps and widgets

Responsive Hardware

Powerful built-in 2.0Ghz quad-core CPU and 4GB RAM, high-speed 1000Base-T network adapter

Hygienic Design

SGS-certified antibacterial components

  OPS
I5
Ram 8GB
SSD 128GB
Windows 10



        s no parameter specification
        2 Model E7520C
        3 Diagonal Size   inch  75
        4 Glass Anti-glare, Tempered
        5 Bonding Zero parallax
        6 Viewing Angle 178 ° ( H / V )
        7 Aspect Ratio 16:9
        8 Backlight DLED
        9 Resolution 3840 x 2160
        10 Contrast Ratio 1200: 1
        11 Color Depth 1.078 ( 10bit )
        12 Color Gamut ( typ. ) 72 % NTSC
        13 Color Accuracy Delta E s 2
        14 Refresh Rate 60Hz
        15 Response Time 8ms



         MaxHub Interactive Flat Panel Built-in System

           s no parameter  specification
        1 Operating System  Windows
        2 RAM 8GB
        3 CPU 2.0GHz quad core ARM A55
        4 GPU Mali - G52 MP2



         MaxHub Interactive Flat Panel  Environment
          s no parameter  specification
        1 Operating Temperature OC - 40C
        2 Storage Temperature 20 C - 60 C
        3 Operating Humidity 10 % -90 % RH
        4 Storage Humidity 10 % -90 % RH



           speaker
        Sound Channel 2.0
        Power Output 2 x 12W



         Interactivity
        s no parameter     specification
        1 Touch Sensor Infrared ( IR )
        2 Touch Tool Finger, Gesture , Stylus
        3 Multitouch Capabilities Up to 40 touch points ( OS dependent )
        4 Response Time ≤ 10ms
        5 Touch Accuracy + 1.5mm
        6 Object Recognition Range 23mm
        7 Stylus Type Passive dual nibs
        8 Supported Operating System
        ( Touch Return )
        Windows 10 / Windows8 / Windows7 / WindowsXP /
        Android / Linux / Mac OS X / Chrome OS

         software

        s no parameter     specifiction
        1 Screen Share Yes
        2 Power Output Yes
        3 On Board Apps Browser , Cloud Drive , System Keeper , Note , Palette , Annotate , Timer , Screen Record , Split Screen , Screen Lock , etc.



        physical specification
         s no parameter specification
        1 Dimension ( W x H x D ) 1488.1 x 896.3 x 88.3 mm
        2 Shipping Dimension ( W x H x D ) 1628 x 1024 x 208 mm
        3 VESA 600 x 400 mm , M8 x 25 mm



         Accessory

        3m Power Cord
        1.4m HDMI Cable
        5m USB Touch Cable ( Type A - B )
        1.8m USB Type - C Cable
        Remote Control



        conductivity

        s no parameter specification
        1 OPS Slot Yes , 3840 x 2160 @ 60fps
        2 OPS Compatible OPS62A
        3 Wired 000baseT RJ45 x 2
        4 Wi - Fi 2.4Ghz , 5Ghz band 802.11ac / b / g / n / a / ax
        5 HDMI HDMI 2.0 In x 3
        HDMI Out x 1 ( Up to 4K @ 60fps )
        6 Touch USB Type - B x 2
        7 Control RS - 232 x 1
        8 Analog VGA In x 1
        9 Audio Audio In x 1
        Audio Out x 1
        S / PDIF Out x 1
        10 USB Type - A USB 3.0 x 4
        USB 2.0 x 1
        11 Multifunction Port USB Type - C x 1

         certificate

        s no parameter specification
        1 TÜV Rheinland Flicker Free Yes , 3840 x 2160 @ 60fps
        2 TÜV Rheinland Low Blue Light OPS62A
        3 SGS Antibacterial Stylus , Power Button
        Protection Glass ( optional )



        View full details

        Maxhub Smart Board: Unbeatable Features

        Durable Build

        These panels are designed to be durable and robust, suitable for frequent use in professional settings

        Interactive Software

        MAXHUB typically provides interactive software to enhance the usability of their panels, including features for content creation and management.

        Multi-Touch Support

        MAXHUB panels often support multi-touch gestures, allowing multiple users to interact with the screen simultaneously, which is particularly useful in collaborative environments.

        Android Operating System

        Many MAXHUB interactive flat panels run on the Android operating system, providing access to a wide range of apps and software for enhanced functionality.

        PC Integration

        Maxhub panels often have the capability to connect to external devices, such as computers or laptops, to facilitate presentations and collaborative work.

        Built-in Speakers

        Maxhub interactive flat panels often include built-in speakers for audio playback during presentations or video conferences.

        Mounting Options

        Maxhub provides various mounting options, including wall mounts and mobile stands, to suit different installation requirements.

        LET'S DISCUSS SOME PROMINENT FEATURES OF Maxhub interactive flate panel THAT WILL HELP YOU UNDERSTAND WHY YOU SHOULD PURCHASE ONEAS OPPOSED TO ANOTHER flat panels.

        Characters of Maxhub interactive Flate panel

        Touchscreen Functionality

        MAXHUB interactive flat panels feature a touchscreen interface, allowing users to interact with the display using their fingers or a stylus.

        High-Resolution Display

        These panels typically offer high-resolution displays with clear and vibrant visuals, making them suitable for presentations and educational content.

        Multiple Size Options

        MAXHUB offers a range of sizes to cater to different room sizes and usage scenarios, from smaller panels for huddle rooms to larger ones for conference rooms and classrooms.

        Wireless Screen Sharing

        MAXHUB panels often come equipped with wireless screen sharing capabilities, allowing users to easily mirror their devices' screens for presentations and collaboration.

        Maxhub Interactive Flat Panel | Maxhub Panel Review |

        Transform Your Dream Studio with India's Studio Provider Company.

        Edusqaudz is a company that has excelled in the education domain by providing one-stop solutions for various smart classroom online coaching and schools. From interactive flat panels to powerful 4k PTZ cameras and from setting up their dream studio to ensuring sound proficiency, Edusqaudz has become a go-to solution for every audio education need, ranging from the smallest to the largest. This is why it is renowned as India's best studio setup provider company.

        Contact Now for Exclusive Discounts!

        FAQs

        1. Why does it have a image residue on a MAXHUB interactive flat panel?

        The image residue phenomenon, also known as “screen burn-in”, “image burn-in”, “ghost image”, “ghosting”, “screen burn” , etc., is normal during displaying stationery image for extended period of time. In order to help maintain the best performance of the panel, we highly recommend you to set up the screen saver or avoid displaying stationery image for over 1 hour. In order to remove the burnt-in image, you can try displaying dynamic contents for a while or cooling down the device and rebooting it.

        The device is heavy. Is it safe to hang on the wall like this?

        Hanging bracket for MAXHUB has been tested in various settings. The bracket and the wall mount are both robust and reliable.
        But please make sure the wall is strong enough to hold the device and the installation should be in accordance with our official setup guidance. Our trusted resellers have been properly informed of those protocols and professionally trained. We have not received any report of accidents about mounting yet.
        However, it is recommended that you inform your supplier in detail the status of the wall as a safety precaution.

        What if system update failed?

        Power off and unplug the device, keep it idle for 10s before replugging the power, then reboot the device as you normally would.

        4. How long is your product warranty? How to claim a breach of warranty?

        The warranty terms vary from your purchase terms. An extended warranty may have been purchased already. Please contact your supplier for further details about your warranty terms and if applicable, file your claims to them.

        5. Where do I keep the styli (pens)?

        In order not to lose the styli, we strongly advise you to develop a habit of placing the styli on the pen rest or pen box once you complete your session with MAXHUB interactive flat panels. Generally there are two kinds of styli:
        For ordinary styli that come with the standard series interactive flat panels, you can put them on the magnetic pen rests.
        For electromagnetic styli that come with the ultimate series interactive flat panels, you can put them in the pen box (sold separately).
